| Item | SY155C / SY155H | SY155U (Tier4 / Stage V) |
|---|---|---|
| Operating Weight | ~ 14,100 kg (14.1 t) | ~ 16,000 kg (16 t) |
| Standard Bucket Capacity | ~ 0.65 m³ | ~ 0.60 m³ |
| Engine Model | Isuzu 4JJ1 / 4JJ1X | Isuzu AR-4JJ1XASC |
| Displacement | ~ 2.999 L | ~ 2.999 L |
| Rated Power | ~84 kW（≈ 113 hp） | ~78.5 kW（≈ 105 hp） |
| Fuel Tank Capacity | ~240 L | ~220 L |
| Hydraulic Tank Capacity | ~150 L | ~110 L |
| Item | SY155C / SY155H | SY155U (Tier4 / Stage V) |
|---|---|---|
| Operating Weight | ~ 14,100 kg (14.1 t) | ~ 16,000 kg (16 t) |
| Standard Bucket Capacity | ~ 0.65 m³ | ~ 0.60 m³ |
| Engine Model | Isuzu 4JJ1 / 4JJ1X | Isuzu AR-4JJ1XASC |
| Displacement | ~ 2.999 L | ~ 2.999 L |
| Rated Power | ~84 kW（≈ 113 hp） | ~78.5 kW（≈ 105 hp） |
| Fuel Tank Capacity | ~240 L | ~220 L |
| Hydraulic Tank Capacity | ~150 L | ~110 L |
| Indicator | SY155C / SY155H / SY155U |
|---|---|
| Bucket Digging Force (ISO) | ~103 kN |
| Arm Digging Force | ~67 kN |
| Standard Boom Length | ~ 4.6 m |
| Standard Arm Length | ~ 2.5 m |
| Bucket Capacity Range | 0.60–0.65 m³ (slight variations by version) |
Note: SY155C / SY155H versions mainly focus on domestic National III/GBIII configurations, while SY155U introduces stricter Tier 4/Stage V emission standards.
| Item | Typical Value |
|---|---|
| Travel Speed (High/Low Gear) | ~ 5.5 km/h / 3.5 km/h (reported for SY155H) |
| Swing Speed | ~ 12 rpm |
| Gradeability | ~ 70 % (approximately 35°) |
| Ground Pressure | ~ 43 kPa (reported for SY155H) |
Sany’s official data does not fully disclose the detailed dimensions of the SY155 series (such as transport length/width/height, track ground contact length, etc.), but some version parameters are as follows (approximate for SY155H):
| Dimension (Reference for SY155H) | Value |
|---|---|
| Transport Length | ~ 7870 mm |
| Transport Width | ~ 2570 mm |
| Transport Height | ~ 2880 mm |
| Track Shoe Width | ~ 500 mm |
| Minimum Ground Clearance | ~ 425 mm |
| Tail Swing Radius | ~ 2210 mm |
| System | Capacity (Approximate) |
|---|---|
| Fuel Tank | ~ 220 – 240 L |
| Hydraulic Tank | ~ 110 – 150 L |
| Radiator Coolant | ~ 10–27 L |
