I. Basic Specifications
| Item | Parameter / Value |
|---|---|
| Model Name | SANY SY75C Small Hydraulic Excavator |
| Operating Weight | ~ 7,280 – 7,350 kg (approx. 7.3 t) |
| Standard Bucket Capacity | ~ 0.28 – 0.30 m³ |
| Engine Model | Isuzu 4JG3X / 4TNV98C (varies by version configuration) |
| Displacement | ~ 2.999 – 3.319 L |
| Rated Power | ~ 42.4 – 55 kW (≈ 57 – 75 hp) |
I. Basic Specifications
| Item | Parameter / Value |
|---|---|
| Model Name | SANY SY75C Small Hydraulic Excavator |
| Operating Weight | ~ 7,280 – 7,350 kg (approx. 7.3 t) |
| Standard Bucket Capacity | ~ 0.28 – 0.30 m³ |
| Engine Model | Isuzu 4JG3X / 4TNV98C (varies by version configuration) |
| Displacement | ~ 2.999 – 3.319 L |
| Rated Power | ~ 42.4 – 55 kW (≈ 57 – 75 hp) |
🔧 II. Engine and Efficiency
| Parameter | Value / Description |
|---|---|
| Engine Type | 4-Cylinder, Direct Injection, Turbocharged, Water-Cooled Diesel Engine |
| Maximum Torque | ~ 280 N·m (approx.) (some high-power versions) |
⛏️ III. Performance
| Indicator | Typical Value |
|---|---|
| Maximum Digging Depth | ~ 3,840 mm (approx. 3.84 m) |
| Maximum Digging Reach | ~ 6,505 mm |
| Maximum Digging Height | ~ 7,390 mm |
| Maximum Dumping Height | ~ 4,450 mm |
| Bucket Digging Force | ~53 – 56 kN |
| Arm Digging Force | ~35 – 38 kN |
🚶♂️ IV. Travel and Powertrain
| Item | Typical Parameter |
|---|---|
| Travel Speed (High/Low Gear) | ~ 4.4 / 2.4 km/h |
| Swing Speed | ~ 10.5 – 11.5 rpm |
| Gradeability | ~ 70 % (approx. 35°) |
| Ground Pressure | ~ 33 kPa |
📏 V. Dimensions (Typical Transport Configuration)
| Dimension Item | Approx. Value |
|---|---|
| Shipping Length | ~ 6,120 mm |
| Shipping Width | ~ 2,220 mm |
| Shipping Height | ~ 2,675–2,720 mm |
| Track Length on Ground | ~ 2,195 mm |
| Track Shoe Width | ~ 450 mm |
| Minimum Ground Clearance | ~ 380 mm |
| Rear Swing Radius | ~ 1,800 mm |
🛢️ VI. Fluids and Capacities
| System | Capacity |
|---|---|
| Fuel Tank | ~ 150 L |
| Hydraulic Oil Tank | ~ 120 L |
| Engine Oil | ~ 9.5 L |
| Coolant | ~ 6.5 L |
