High Performance Used CAT 329D Crawler Excavator Low Price Construction Equipment

Description

I. Basic Specifications

Model Name: Caterpillar 329D / 329D L Hydraulic Excavator
Engine Model: Cat® C7 with ACERT™ Technology
Engine Displacement: 7.2 L
Net Power (ISO 9249): 152 kW (204 hp)

Operating Weight:

• Standard Undercarriage Version ≈ 26,900 kg
• Long Undercarriage Version ≈ 29,240 kg (Common Configuration)

Fuel Tank Capacity: ~520 L
Swing Speed: ~10.2 rpm
Maximum Travel Speed: ~5.3 km/h

🧱 II. Performance

Item	Parameter
Max. Digging Depth	~6,620 – 7,170 mm (approx. 6.6–7.2 m)
Max. Digging Reach	~10,130 – 10,600 mm
Max. Dumping Height	~9,880 – 9,990 mm
Max. Dumping Clearance Height	~6,870 – 7,020 mm
Bucket Capacity	~1.1 – 1.57 m³ (varies by bucket type)
Bucket Digging Force	~168 kN (typical reference)
Arm Digging Force	~155 kN (typical reference)

🌀 III. Hydraulic System

Main Pump Max. Flow: ~235 L/min
Equipment Max. Working Pressure: ~35,000 kPa
Travel Circuit Pressure: ~35,000 kPa
Swing Circuit Pressure: ~27,500 kPa
Pilot System Pressure: ~3,900 kPa

🛞 IV. Undercarriage & Travel

Parameter	Value
Shoe Width (Standard)	~600 mm
Overall Track Width	~3,390 mm
Track Gauge	~2,590 mm
Counterweight Ground Clearance	~1,080 mm
Shipping Length	~10,410 mm
Shipping Width	~2,990 mm
Cab Height	~3,040 mm

🛢️ V. Refill Capacities (Reference)

System	Capacity
Fuel Tank	~520 L
Hydraulic System (incl. tank)	~310 L
Hydraulic Oil Tank	~257 L
Engine Oil	~30 L
Coolant	~30 L
Swing Drive	~10 L
Final Drive (each side)	~6 L

Shipping

FAQ

• Q

  What used construction machines do you mainly supply?

  A

  We supply used excavators, loaders, motor graders, road rollers, forklifts, etc.
• Q

  What brands of machines are available?

  A

  Our main brands include Caterpillar, Komatsu, Doosan, Hitachi, Kubota, Hyundai, Volvo, and other well-known brands.
• Q

  Do you export to overseas markets?

  A

  Yes, we have rich export experience and a professional shipping team. Our customers are from South America, Europe, Africa, and all over the world.
• Q

  How about the quality and price of your machines?

  A

  All our machines are in good working condition with reliable performance and competitive prices. All prices of the machine can be negotiated.
