Bobcat S630 Used Skid Steer Loader Strong Power for Construction Use

Description

Basic Performance

Model Name

Bobcat S630 Skid-Steer Loader

Engine and Power

Engine Model: Kubota V3307-DI-TE3 (4-cylinder, water-cooled diesel)

Rated Power: ≈ 55.4 kW ≈ 74.3 hp @ 2400 rpm (SAE standard)

Displacement: Approx. 3331 cm³ (3.3 L)

Fuel Tank Capacity: Approx. 90.5 – 103.1 L (varies slightly depending on version)

Emission Standard: Tier 4 / Stage V compliant (actual configuration depends on market conditions)

⚖️ Weight and Load

Operating Weight: Approx. 3,496 kg

Rated Working Load (ISO 14397-1): ≈ 1,040 kg

Tilting Load: Approx. 2,079 kg

🪣 Operational Performance

Lifting Mechanism Type: Radial Lift

Standard Auxiliary Hydraulic Flow Rate: Approx. 87.1 L/min

High Flow Optional: Approx. 115.5 L/min

System Safety Pressure: Approx. 23.8-24.5 MPa

🚗 Driving Performance

Maximum Travel Speed: Approx. 11.4 km/h (Standard)

Optional Two-Speed ​​Travel: Approx. 19.8 km/h

📏 Dimensions (Typical)

Parameters Values
Overall Length (including bucket) ≈ 3,475 mm
Width (tires) ≈ 1,831 mm
Width (including bucket) ≈ 1,880 mm
Overall Height (cab top) ≈ 2,065 mm
Maximum Bucket Hinge Pin Height ≈ 3,073 mm
Maximum Unloading Distance ≈ 544 mm
Turn Radius ≈ 2,118 mm
Wheelbase ≈ 1,151 mm
