| Item | Parameter |
|---|---|
| Model | Volvo EC140D (Medium-sized Hydraulic Excavator) |
| Category | Medium Crawler Excavator |
| Operating Weight | ~13,000 – 16,730 kg (Varies by Configuration) |
| Rated Engine Power (Gross) | 77.4 kW (≈105 hp) @ 2,200 rpm |
| Emission Standard | Stage IIIA / Tier 3 (Implemented in select markets) |
| Standard Bucket Capacity | 0.60 – 0.64 m³ |
| Item | Parameter |
|---|---|
| Model | Volvo EC140D (Medium-sized Hydraulic Excavator) |
| Category | Medium Crawler Excavator |
| Operating Weight | ~13,000 – 16,730 kg (Varies by Configuration) |
| Rated Engine Power (Gross) | 77.4 kW (≈105 hp) @ 2,200 rpm |
| Emission Standard | Stage IIIA / Tier 3 (Implemented in select markets) |
| Standard Bucket Capacity | 0.60 – 0.64 m³ |
| Operating Item | Parameter |
|---|---|
| Maximum Digging Depth | ~5,530 mm |
| Maximum Digging Radius | ~8,330 mm |
| Maximum Dumping Height | ~6,020 mm (Typical Configuration) |
| Vertical Wall Digging Depth | ~4,960 mm (Slight variation with configurable arm) |
| Horizontal Digging Range (at ground level) | ~8,190 mm |
| Indicator | Value |
|---|---|
| Bucket Digging Force (Standard / Boost) | 82.2 kN / 87.2 kN (ISO SAE J1179) |
| Arm Digging Force (Standard / Boost) | 61.8 kN / 65.5 kN (ISO SAE J1179) |
| Lifting Capacity (on chassis) | ~3,500 kg (at 6 m reach / 1.5 m height) |
| Dimension Item | Value |
|---|---|
| Overall Width | ~2,590 mm |
| Tail Swing Radius | ~2,200 mm |
| Track Gauge (Track Width) | ~1,990 mm (Slight variation with track shoe width) |
| Minimum Ground Clearance | ~436 mm |
| Total Length (Including Arm/Bucket) | ~7,720 mm (Standard arm / configuration example) |
| Total Height (Cab) | ~2,830 mm |
| Subsystem | Parameter |
|---|---|
| Hydraulic Pump | Dual Variable Displacement Pumps (Standard) + Pilot Pump (Details vary by market) |
| Hydraulic System Capacity | ~230 L total, Hydraulic Tank ~85 L (Data varies by market) |
| Fuel Tank Capacity | ~250 L |
| Travel Speed | Two-speed variable; travel power is automatically switched by crawler drive motors (Specific values vary slightly by country configuration) |
| Swing Speed | ~11 rpm |
