| Item | Parameter |
|---|---|
| Model | Volvo EC210D Medium-sized Hydraulic Excavator |
| Operating Weight | 18,100 – 22,800 kg (Affected by configuration and bucket size) |
| Engine Model | Volvo D5E Turbocharged Diesel Engine |
| Rated Engine Power | 123 kW @ 2,000 rpm (≈165 hp) |
| Bucket Capacity | 0.52 – 1.22 m³ |
| Application | Medium earthmoving, infrastructure construction, municipal engineering, general construction works |
| Item | Parameter |
|---|---|
| Model | Volvo EC210D Medium-sized Hydraulic Excavator |
| Operating Weight | 18,100 – 22,800 kg (Affected by configuration and bucket size) |
| Engine Model | Volvo D5E Turbocharged Diesel Engine |
| Rated Engine Power | 123 kW @ 2,000 rpm (≈165 hp) |
| Bucket Capacity | 0.52 – 1.22 m³ |
| Application | Medium earthmoving, infrastructure construction, municipal engineering, general construction works |
| Parameter | Value |
|---|---|
| Engine Displacement | ≈ 4.7 L (4-Cylinder) |
| Maximum Torque | ≈ 670 Nm @ ~1,600 rpm |
| Travel Speed | ~3.5 – 5.8 km/h (Low/High) |
| Swing Speed | ≈ 12.3 rpm |
| Traction Force / Maximum Pulling Force | ~183 kN (Configuration example) |
| Indicator | Value |
|---|---|
| Maximum Digging Depth | ~6,730 mm |
| Maximum Digging Radius | ~9,930 mm |
| Bucket Digging Force (Standard) | ~123 kN |
| Bucket Digging Force (Boost) | ~130 kN |
| Arm Digging Force (Standard) | ~96 kN |
| Arm Digging Force (Boost) | ~102 kN |
| Lifting Capacity (on chassis) | ~7,240 kg @ 6 m reach / 1.5 m height |
| Item | Value |
|---|---|
| Total Width (Upper Carbody) | ~2,800 mm |
| Tail Swing Radius | ~2,850 mm |
| Track Shoe Width | Typically 600 mm (Varies by market/configuration) |
| Minimum Ground Clearance | ~460 mm (Typical Configuration) |
| Boom/Arm | Boom ~5.7 m / Arm ~2.9 m (Common configuration) |
(Configuration reference for select markets)
Main Pump Type: Dual Variable Displacement Piston Pumps
Maximum Main Pump Flow: ≈ 2×207 – 2×212 L/min
Hydraulic Working Pressure: Approximately 32.4 MPa (Working) / 27.9 MPa (Swing)
Fuel Tank Capacity: ~300 L
