I. Basic Machine Specifications
| Item | Typical Value / Description |
|---|---|
| Model Series | Hitachi ZX210 / ZX210H / ZX210LC |
| Operating Weight | ~ 20,400 – 21,200 kg (depends on version and track configuration) |
| Standard Bucket Capacity | ~ 0.91 – 1.0 m³ (common backhoe bucket) |
| Engine Model | Isuzu 4HK1 / Isuzu AA-6BG1T (4-cylinder / 6-cylinder diesel) |
| Emission Standard | EPA Tier 4 / EU Stage IV (some newer versions like ZX210-6) |
I. Basic Machine Specifications
| Item | Typical Value / Description |
|---|---|
| Model Series | Hitachi ZX210 / ZX210H / ZX210LC |
| Operating Weight | ~ 20,400 – 21,200 kg (depends on version and track configuration) |
| Standard Bucket Capacity | ~ 0.91 – 1.0 m³ (common backhoe bucket) |
| Engine Model | Isuzu 4HK1 / Isuzu AA-6BG1T (4-cylinder / 6-cylinder diesel) |
| Emission Standard | EPA Tier 4 / EU Stage IV (some newer versions like ZX210-6) |
🔧 II. Engine and Power
| Indicator | Parameter |
|---|---|
| Net Engine Power | ~ 119 kW (160 hp) @ 2000 rpm (ZX210-6 example) |
| Displacement | ~ 5.19 L (≈ 317 cu in) |
| Number of Cylinders | 4 (ZX210-6) |
| Turbocharging Type | Turbocharged + Intercooled (Direct Injection) |
| Maximum Torque | ~ 550 Nm @ 1600 rpm (some versions) |
🏗️ III. Hydraulic System
| Item | Value / Description |
|---|---|
| Main Pump Type | Dual Variable Axial Piston Pump (includes pilot pump) |
| Main Pump Rated Flow | ~ 2 × 212 L/min (56 gpm) (ZX210-6) |
| Total Hydraulic System Oil Capacity | ~ 240 L (approx. 63 gal) |
| Hydraulic Oil Tank Capacity | ~ 135 L (approx. 36 gal) |
| Working Pressure | ~ 34.3 MPa (≈ 343 bar) (standard circuit) |
🛠️ IV. Performance
| Item | Typical Value / Description |
|---|---|
| Maximum Digging Depth | ~ 6,670 mm (approx. 6.67 m) |
| Maximum Digging Reach (at ground level) | ~ 9,750 – 9,920 mm (approx. 9.75 – 9.92 m) |
| Maximum Dumping Height | ~ 7,180 mm (approx. 7.18 m) |
| Maximum Vertical Digging Depth | ~ 5,990 mm (approx. 5.99 m) |
| Bucket Digging Force (ISO) | ~ 151–165 kN (common range, varies slightly by version) |
| Arm Digging Force | ~ 109–110 kN (typical) |
🚶♂️ V. Travel and Movement Performance
| Indicator | Value |
|---|---|
| Travel Speed (High/Low) | ~ 5.5 km/h / ~3.5 km/h |
| Swing Speed | ~ 13.3–13.5 rpm |
| Maximum Drawbar Pull | ~ 203 kN (approx. 20.7 t) |
| Gradeability | ~ 70 % (35°) |
| Ground Pressure | ~ 44–47 kPa (depending on track width) |
📏 VI. Dimensions and Weight (Transport Configuration)
| Dimension Item | Typical Value |
|---|---|
| Shipping Length | ~ 9,660 mm |
| Shipping Width | ~ 2,860–2,880 mm |
| Shipping Height | ~ 3,010 mm |
| Track Length on Ground | ~ 3,370 mm |
| Minimum Ground Clearance | ~ 450 mm |
| Tail Swing Radius | ~ 2,890–3,180 mm |
| Track Shoe Width | ~ 600 mm |
🛢️ VII. Fluids and Capacities
| System | Approx. Capacity |
|---|---|
| Fuel Tank | ~ 400 L (106 gal) |
| Engine Oil | ~ 23 L |
| Coolant | ~ 28 L |
| Swing Drive Oil | ~ 6.2 L |
