Used Hitachi ZX200-3G Excavator Original Engine Good Performance

Description

I. Basic Machine Specifications

Parameter	Value / Description
Model Name	Hitachi ZX200-3G Tracked Hydraulic Excavator
Operating Weight	~ 19,800 kg – ~20,050 kg (approx. 19.8 – 20.1 t)
Standard Bucket Capacity	~ 0.8 m³ (common configuration)
Engine Model	Isuzu AA-6BG1T 6-Cylinder Turbocharged Diesel Engine
Engine Displacement	~ 6.494 L
Rated Power	~ 110 kW / ~150 hp (approx. 147 hp)
Maximum Torque	~ 550 Nm
Fuel Tank Capacity	~ 400 L
Emission Standard	Typical Tier 2 / Stage II (some regions)

⛏️ II. Performance (Typical)

Indicator	Typical Value
Maximum Digging Depth	~ 6,660 mm
Maximum Horizontal Reach (at ground level)	~ 9,750 mm
Maximum Dumping Height	~ 6,790 mm (some sources)
Maximum Working Height	~ 9,610 mm (some application versions)
Ground Force/Digging Force (Reference)	~ 151 kN (typical bucket tear-out)

Note: Specific values may vary slightly depending on bucket size, arm/stick combinations, and configuration.

⚙️ III. Hydraulic and Powertrain System

Item	Data / Description
Hydraulic Pump Flow	~ 2 × 208 L/min (some sources)
Working Pressure	~ 34.3 MPa (approx. 343 bar)
Hydraulic System Oil Capacity	~ 240 L
Swing Speed	~ 13.3 rpm

🚶‍♂️ IV. Travel and Undercarriage

Item	Typical Value
Maximum Travel Speed	~ 5.5 km/h (high gear) / ~ 3.6 km/h (low gear)
Minimum Ground Clearance	~ 450 mm
Track Width	~ 600 mm
Track Length on Ground	~ 3370 mm
Ground Pressure	~ 44 kPa
Gradeability	~ 70 % (reference market configuration)

📏 V. Dimensions (Typical Transport Configuration)

Dimension	Approx. Value
Shipping Length	~ 9,500 – 9,930 mm
Shipping Width	~ 2,860 mm
Shipping Height	~ 2,970 mm
Tail Swing Radius	~ 2,750 mm

🔋 VI. Main Refill Capacities (Reference)

System	Capacity
Fuel Tank	~ 400 L
Engine Oil	~ 23 L
Coolant	~ 26 L
Swing Drive Oil	~ 6 L

Shipping

FAQ

• Q

  What used construction machines do you mainly supply?

  A

  We supply used excavators, loaders, motor graders, road rollers, forklifts, etc.
• Q

  What brands of machines are available?

  A

  Our main brands include Caterpillar, Komatsu, Doosan, Hitachi, Kubota, Hyundai, Volvo, and other well-known brands.
• Q

  Do you export to overseas markets?

  A

  Yes, we have rich export experience and a professional shipping team. Our customers are from South America, Europe, Africa, and all over the world.
• Q

  How about the quality and price of your machines?

  A

  All our machines are in good working condition with reliable performance and competitive prices. All prices of the machine can be negotiated.
