Heavy Duty Used CAT 345GC Excavator Durable Construction Machines Factory Price

Description

I. Basic Specifications

Model Name: Caterpillar 345 GC Hydraulic Excavator
Engine Model: Cat® C9.3 Turbocharged Diesel Engine
Net Power (ISO 9249): 346 hp / 258 kW
Rated Power (ISO 14396): 347 hp / 259 kW
Displacement: 9.3 L (568 in³)
Operating Weight: Approx. 42,200 kg (approx. 93,000 lb)
Fuel Tank Capacity: ~600 L

🛠️ II. Performance and Ranges

Item	Standard Value
Maximum Digging Depth	~7,200 mm (23.6 ft)
Maximum Horizontal Reach at Ground Level	~11,290 mm (37 ft)
Maximum Cutting Height	~10,540 mm (34.6 ft)
Maximum Loading Height	~7,210 mm (23.7 ft)
Max. Digging Depth for 2440 mm Flat Floor	~7,040 mm
Maximum Vertical Wall Digging Depth	~5,390 mm
Bucket Capacity (HD Standard)	~2.41 m³ (3.15 yd³)
Bucket Digging Force (ISO)	~235 kN
Arm Digging Force (ISO)	~180 kN

💧 III. Hydraulic System Parameters

Main Pump Maximum Flow (Total): ~630 L/min (166 gal/min)
Maximum Equipment Working Pressure: 35,000 kPa (5076 psi)
Maximum Swing Pressure: 28,000 kPa (4061 psi)

🔄 IV. Swing and Drive

Swing Speed: ~8.27 rpm
Maximum Swing Torque: ~155 kN·m

📏 V. Dimensions (Typical)

Dimension Item	Value
Shipping Length	~11,600 mm (38.1 ft)
Shipping Height (Top of Cab)	~3,230 mm (10.6 ft)
Tail Swing Radius	~3,530 mm (11.6 ft)
Ground Clearance	~520 mm
Track Length	~5,030 mm
Track Gauge	~2,740 mm
Shipping Width	~3,340 mm

🛢️ VI. Refill Capacities (Reference)

System	Capacity
Fuel	~600 L
Coolant	~40 L
Engine Oil	~32 L
Swing Drive	~13.5 L
Final Drive (each side)	~8 L
Hydraulic System (including tank)	~423 L
Hydraulic Oil Tank	~186 L

Shipping

FAQ

• Q

  What used construction machines do you mainly supply?

  A

  We supply used excavators, loaders, motor graders, road rollers, forklifts, etc.
• Q

  What brands of machines are available?

  A

  Our main brands include Caterpillar, Komatsu, Doosan, Hitachi, Kubota, Hyundai, Volvo, and other well-known brands.
• Q

  Do you export to overseas markets?

  A

  Yes, we have rich export experience and a professional shipping team. Our customers are from South America, Europe, Africa, and all over the world.
• Q

  How about the quality and price of your machines?

  A

  All our machines are in good working condition with reliable performance and competitive prices. All prices of the machine can be negotiated.
