Hot Sale Used CAT 330GC Excavator Competitive Price Good Condition Solution

Description

I. Basic Parameters

Model Name: Caterpillar 330 GC Hydraulic Excavator
Engine Model: Cat® C7.1 Turbocharged Diesel Engine
Rated Net Power (ISO 9249):

• Approx. 201 hp / 150 kW (Tier 4 / Stage V version)
• Approx. 212 hp / 158 kW for some market standards (Tier 3)

Operating Weight:

• Approx. 30,400 kg (~67,000 lb) (HD configuration example)
• Approx. 30,900 kg (~68,100 lb) for high-spec (Stage V version)

Fuel Tank Capacity: ~474 L

🛠️ II. Performance

Item	Value
Maximum Digging Depth	~7,260 mm (23.8 ft)
Maximum Reach at Ground Level	~10,690 mm (35.1 ft)
Maximum Cutting Height	~9,980 mm (32.9 ft)
Maximum Loading Height	~6,930 mm (22.8 ft)
Maximum Digging Depth for Flat Floor (8 ft)	~7,100 mm (23.3 ft)
Maximum Vertical Wall Digging Depth	~5,800 mm (19.0 ft)
Bucket Digging Force (ISO)	~179 kN
Arm Digging Force (ISO)	~126 kN

*Standard configuration example: Long Arm ~6.15 m, Long Stick ~3.2 m, Heavy-Duty Bucket ~1.60 m³*

💧 III. Hydraulic System

Parameter	Value
Main System Maximum Flow	~560 L/min (148 gal/min)
Maximum Working Pressure (Equipment/Travel)	35,000 kPa
Maximum Swing Pressure	28,400 kPa
Swing Speed	~11.5 rpm
Maximum Swing Torque	~105 kN·m

📏 IV. Dimensions (Typical)

Item	Value
Transport Height (Top of Cab)	~3,050 mm
Shipping Length	~10,420 mm
Tail Swing Radius	~3,130 mm
Ground Clearance	~490 mm
Track Length (on Ground)	~4,350 mm
Track Gauge	~2,390 mm
Shipping Width	~3,190 mm

🛢️ V. Refill Capacities

System	Capacity
Fuel Tank	~474 L
Cooling System	~25 L
Engine Oil	~25 L
Swing Drive (each)	~10 L
Final Drive (each)	~5.5 L
Hydraulic System (including tank)	~310 L
Hydraulic Oil Tank	~147 L
