| Parameter | Typical Value / Range |
|---|---|
| Operating Weight | ~12,200 – 16,100 kg (approx. 12.2 – 16.1 t) |
| Standard Bucket Capacity | ~0.19 – 0.66 m³ (varies by bucket) |
| Engine | ISUZU 4JJ1 4-Cylinder Turbo Diesel Engine (with EFI/Turbo Intercooler) |
| Rated Net Power | 66 – 78.5 kW (approx. 88.5 – 106 hp) |
| Emission Standard | Stage V / Tier 2 / Tier 3 (depending on regional version) |
I. Basic Specifications
Model Name (Common Versions)
✔ ZX130-5G
✔ ZX130-5B
✔ ZX130-7B / ZX130-7H (Newer/Upgraded Version)
| Parameter | Typical Value / Range |
|---|---|
| Operating Weight | ~12,200 – 16,100 kg (approx. 12.2 – 16.1 t) |
| Standard Bucket Capacity | ~0.19 – 0.66 m³ (varies by bucket) |
| Engine | ISUZU 4JJ1 4-Cylinder Turbo Diesel Engine (with EFI/Turbo Intercooler) |
| Rated Net Power | 66 – 78.5 kW (approx. 88.5 – 106 hp) |
| Emission Standard | Stage V / Tier 2 / Tier 3 (depending on regional version) |
🔧 II. Engine and Power
| Parameter | Value |
|---|---|
| Engine Model | ISUZU 4JJ1 (or equivalent diesel engine) |
| Number of Cylinders | 4 |
| Displacement | ~3,000 cm³ (≈3.0 L) |
| Rated Net Power | 66 – 78.5 kW @ ~2000 rpm (approx. 88 – 107 hp) |
| Maximum Torque | Approx. 375 Nm (some versions) |
| Hydraulic Pump | Dual Variable Displacement Piston Pump + Pilot Gear Pump Configuration |
🛠️ III. Performance
*⭐ ZX130-7B / ZX130-7H (Newer Versions)*
| Indicator | Typical Value |
|---|---|
| Maximum Digging Depth | ~4,910 – 6,020 mm (with different boom/stick options) |
| Maximum Working Radius (at ground level) | ~7,930 – 8,780 mm |
| Maximum Dumping Height | ~5,990 – 7,390 mm |
| Maximum Digging Force (Bucket) | ~104 kN ISO |
*⭐ ZX130-5G / ZX130-5B (Earlier Versions)*
| Indicator | Typical Value |
|---|---|
| Maximum Digging Depth | ~5,120 – 6,030 mm |
| Maximum Digging Reach | ~8,170 – 8,650 mm |
| Bucket Digging Force | ~104 kN (ISO) |
| سعة الدلو | ~0.19 – 0.59 m³ |
🚶♂️ IV. Travel and Swing Performance
| Indicator | Typical Value |
|---|---|
| Travel Speed | Approx. 5.0–5.5 km/h (standard mid/high gear) |
| Swing Speed | ~13 – 14 rpm (old and new versions) |
| Ground Pressure | ~32–48 kPa (depending on track width/configuration) |
📏 V. Dimensions (Typical)
| Dimension Item | Approximate Value |
|---|---|
| Overall Length | ~7,710–8,900 mm (depends on boom/stick) |
| Overall Width | ~2,490–2,590 mm |
| Overall Height (Top of Cab) | ~2,790 – 2,870 mm |
| Track Length on Ground | ~3,580–3,750 mm |
| Track Width | ~500–700 mm |
| Tail Swing Radius | ~2,130–2,620 mm |
🛢️ VI. Fluids & Capacities (Reference)
| System | Approx. Capacity |
|---|---|
| Fuel Tank | ~250–285 L |
| Hydraulic Oil Tank | ~69–130 L |
| Engine Oil | ~15–18 L |
| Coolant | ~19–21 L |
